Antenna gain: ≥6.5dB
Amplifier gain: OdB-15dB(+/-1.5dB)
Antenna impedance: 50Ω
Power supply: 8V, 40mA
Output: OIP3>28dBm
Connector port: BNC female head
Can be used with antenna power supply function of the receiver and antenna distribution system.
Antenna frequency range: 450-950mhz
Amplifier frequency range: 450-950MHz
Antenna gain: ≥6.5dB
Amplifier gain: OdB-15dB(+/-1.5dB)
Antenna impedance: 50Ω
Power supply: 8V, 40mA
Output: OIP3>28dBm
Connector port: BNC female head
Frequency range: 450MHz-950MHz
Total gain: OdB, ±1dB
Input/output impedance: 50ohms
Antenna power supply: +8V DC/150mA central point is positive
DC output: 12V DC/3A(MAX)*4 groups of central point is positive
Battery display on LCD
S/N ratio: >105dB
T.H.D distortion: <0.5%
Frequency response: 20Hz–18KHz
Distance: 50-80 meters approx
